Model
Maestro – MTS4-10-4
KNX Touch Screen Server
System
CPU – Allwinner A64, 64bit 4 core.
DDR – 1GB DDR3.
FLASH – 8GB EMMC Flash.
TF CARD – Max. 128GB.
Relay output – 4CH, 1A 30VDC Max. per channel.
6 channels dry contact input.
Built In Speaker.
Built In Microphone.
Built In Camera – 2.0 megapixel, 1616×1232.
Built-in human motion sensor and temperature sensor.
LCD & Touch screen
Panel Type – HD IPS 10.1″ Multi Point Capacitive Touch Screen.
Resolution: 1280W x 800H.
Dimensions: 270×209×40 (mm).
Housing Material: Glass, PC, ABS, Aluminum allo.
I/O
Ethernet Port – RJ45 10/100 M to support LAN and internet via wired Ethernet port1xRS232.
USB 2.0.
HDL Buspro.
KNX.
Power
Power supply – 9~25VDC.
Wall cut out dimensions
203mm(H) x 263mm(W) x 51mm(D).
Environmental & Physical
Operating temperature – -5℃~45℃.
Regulatory
CE, RoHS.
IP 20.
For product features please go to our Features page.
Model
Maestro – MS4-4K
KNX Server
Model |
Standard ports |
Additional Ports |
MS4-4KM |
1xKNX 1xLAN | None |
MS4-4KMU |
1xKNX 1xLAN | 4x USB 3.0 |
MS4-4K485 |
1xKNX 1xLAN | 1xRS485 port |
MS4-4K485U |
1xKNX 1xLAN | 1xRS485 port + 4x USB 3.0 |
System
CPU – Quad core 1.5GHz.
RAM – 2G.
FLASH – 8G.
No moving parts.
I/O
KNX
10/100/1000 Base-T Ethernet.
4xUSB (optional).
RS485 (optional).
1xDHCP/STATC IP button
Display
128×64 LCD
Power
AC/DC adapter 90-240VAC output 12VDC 2A.
Dimensions
117mm(W) x 94mm(H) x 42mm(D).
Environmental & Physical
Operating temperature – 0 ~ 45c.
Regulatory
CE, RoHS.
IP 20.
For product features please go to our Features page.
Model
Maestro Server
MS4-4N
(Not Including KNX Interface)
KNX Server
System
CPU – Quad core 1.5GHz.
RAM – 1G.
FLASH – 8G.
No moving parts.
I/O
10/100/1000 Base -T Ethernet.
4xUSB.
HDMI.
Power
AC/DC adapter 90-240VAC output 5VDC 2A.
Dimensions
91mm(H) x 72mm(W) x 62mm(D).
Environmental & Physical
Operating temperature – 0 ~ 45c.
Regulatory
CE, RoHS.
IP 20.
For product features please go to our Features page.
